Growatt 100kW On-Grid Inverter (Model: MAX 100KTL3-X LV)

Growatt 100kW On-Grid Inverter (Model: MAX 100KTL3-X LV)

Key Specifications:

• Type: Three-phase, transformerless

• Maximum Efficiency: Up to 98.4%

• MPPT Inputs: 6 MPPTs with 12 strings

• Max DC Input Voltage: 1100V

• Nominal Grid Voltage: 230/400V

• Nominal Frequency: 50/60Hz

• Display: OLED with touch buttons

• Protection Features: Type II SPD on both DC and AC sides, optional AFCI protection

• Protection Rating: IP65 (dust-tight and water-resistant)

• Monitoring Interfaces: RS485, USB, optional Wi-Fi, GPRS, RF, LAN

• Weight: Approximately 75 kg

• Warranty: 5 years standard, extendable to 10 years
