Huawei SUN2000-10KTL-M1 (10kW, Three-Phase Hybrid Inverter)

Huawei SUN2000-10KTL-M1 (10kW, Three-Phase Hybrid Inverter)

Key Specifications:

• Rated AC Output Power: 10,000 W

• Maximum Efficiency: 98.6%

• European Efficiency: 98.1%

• Max PV Input Voltage: 1,100 V

• MPPTs / Strings per MPPT: 2 MPPTs / 2 strings

• Max Input Current per MPPT: 13.5 A

• Operating Voltage Range: 140 V – 980 V

• Battery Compatibility: Huawei LUNA2000 (Lithium-ion)

• Battery Voltage Range: 600 V – 980 V

• Backup Power Support: Yes (requires Huawei Backup Box)

• Cooling Method: Natural convection (fanless)

• Protection Rating: IP65 (dust and water resistant)

• Dimensions: 525 x 470 x 146.5 mm

• Weight: 17 kg

• Communication Interfaces: RS485, WLAN, optional 4G dongle
